INVT VFD GD20 Series Original General Purpose Vector
As an authorized INVT electrical distributor, we provide 100% genuine INVT GD20 Series VFDs. This high-performance vector frequency inverter covers 0.4kW to 110kW, with SVC+V/F dual control, full protection functions, for precise motor speed control. Widely used in pumps, fans, machine tools and production lines. Large in stock, global wholesale, fast delivery, pre-shipment quality inspection.
Product Overview & Technical Features
The INVT GD20 Series (Goodrive20) is a flagship high-performance general purpose vector variable frequency drive developed by INVT, designed for industrial three-phase AC motor speed and torque control applications. It replaces traditional direct start and simple speed regulation solutions, effectively reducing inrush current, mechanical shock and equipment wear, greatly extending the service life of motors and industrial systems.
With dual control modes of sensorless vector control (SVC) and V/F control, it delivers excellent low-speed torque performance and fast dynamic response. Built-in full-range protection functions, standard Modbus-RTU RS485 communication interface, and rich I/O terminals meet the strict requirements of global industrial automation. All products we supply are 100% original INVT genuine products, with complete certifications and traceable serial numbers.
| Parameter | Specification |
|---|---|
| Product Series | GD20 Series |
| Brand | INVT |
| Rated Power Range | 0.4kW to 110kW |
| Input Power Supply | Single-phase 220V AC; Three-phase 220V AC; Three-phase 380V AC |
| Rated Output Frequency Range | 0~400Hz |
| Core Control Mode | Sensorless Vector Control (SVC) + V/F Control |
| Speed Regulation Range | 1:100 |
| Speed Control Accuracy | ±0.2% |
| Overload Capacity | 150% rated current for 1 minute, 180% rated current for 10 seconds |
| Protection Level | IP20 |
| Compatible Motor | Three-phase AC Asynchronous Motors |
| Origin | Original INVT Factory |
| Certification | CE, RoHS, ISO, International Industrial Certification |
Core Advantages of INVT GD20 Series
1.100% Original Genuine Guarantee
Authorized INVT distributor supply, zero counterfeit risk, full quality assurance, each unit with unique traceable serial number and complete certification documents.
2.High-Performance Vector Control
Superior low-speed torque output (150% rated torque at 0.5Hz), fast dynamic response, high-precision speed and torque control for complex industrial working conditions.
3.Full Power Range & Flexible Adaptation
Wide power coverage from 0.4kW to 110kW, multiple voltage specifications available, perfectly compatible with various small to medium power industrial motors.
4.Rich Functions & Strong Expandability
Standard built-in braking unit (≤37kW), RS485 communication interface, rich I/O terminals, support for simple PLC, multi-stage speed, PID control and industry-specific application macros.
5.High Reliability & Long Service Life
Independent air duct design, wide operating temperature range (-10℃~50℃), full-dimension protection functions (overcurrent, overvoltage, phase loss, overload, overheating), stable operation in harsh industrial environments.
6.Large Stock & Fast Global Delivery
Full power range in bulk stock, support sample order and large wholesale, ship within 24-48 hours after payment, with professional pre-shipment 100% quality inspection.
Typical Application Scenarios
- Water Supply & Pump Control Systems
- Industrial Fans & Ventilation Equipment
- Machine Tools & Metal Processing Machinery
- Conveyor Belts & Automated Production Lines
- Food & Packaging Machinery
- Textile, Printing & Dyeing Equipment
- Ceramic, Chemical & Plastic Machinery
- HVAC & Building Automation Systems
- Material Handling & Lifting Equipment
Remarks
- Product quality: 100% original brand new genuine products, supplied via official channels.
- Warranty policy: 1 year official warranty is provided.
- Lead time: Standard lead time is 4–6 weeks; the exact delivery time is subject to the factory production schedule at that time.
- Prices of industrial control products are subject to market and raw material fluctuations. Please contact online customer service for the latest quotes and delivery times.
