Siemens SINAMICS S210

Siemens SINAMICS S210 is a compact, high-performance single-axis servo drive system built for highly dynamic industrial motion control applications. Tailored for mid-range machinery requirements, this advanced servo solution fills the performance gap between basic general-purpose frequency converters and complex high-end multi-axis drive systems. Engineered for simplicity, precise motion control, and integrated functional safety, the complete SINAMICS S210 system integrates high-efficiency servo converters, matched synchronous servomotors, and standardized cable assemblies to deliver streamlined, reliable, and cost-effective industrial automation operation.

${{shopModel.rebate>0?shopModel.discountPriceStr:shopModel.formattedAmount}} ~~$ {{shopModel.formattedAmount}}~~

COUPON

Quantity：

Estimated Delivery Date: Jun 05 - Jun 05

Frequently Asked Questions

How to inquire about other products I am interested in?

Are the products genuine official originals?

Can the delivery time be shortened?

Specifications

Description

Reviews

Product Overview & Technical Features

Siemens SINAMICS S210 is a compact, high-performance single-axis servo drive system built for highly dynamic industrial motion control applications. Tailored for mid-range machinery requirements, this advanced servo solution fills the performance gap between basic general-purpose frequency converters and complex high-end multi-axis drive systems. Engineered for simplicity, precise motion control, and integrated functional safety, the complete SINAMICS S210 system integrates high-efficiency servo converters, matched synchronous servomotors, and standardized cable assemblies to deliver streamlined, reliable, and cost-effective industrial automation operation.

Parameter	Specification
Applicable Motor Series	SINAMICS S210SIMOTICS S-1FK2 / S-1FT2SIMOTICS S-1FS2
Power Range	1 AC 200–240 V / 0.1 kW – 0.75 kW3 AC 200–240 V / 0.24 kW – 4.2 kW3 AC 380–480 V / 0.4 kW – 7 kW1 AC 200–240 V / 0.05 kW – 0.75 kW3 AC 200–240 V / 0.05 kW – 3.9 kW3 AC 380–480 V / 0.4 kW – 6.4 kW1 AC 200–240 V / 0.8 kW3 AC 200–240 V / 0.45 kW – 1.7 kW3 AC 380–480 V / 0.8 kW – 1.9 kW
Torque Range	1 AC 200–240 V / 0.16 Nm – 3.6 Nm3 AC 200–240 V / 0.16 Nm – 40 Nm3 AC 380–480 V / 1.27 Nm – 40 Nm1 AC 200–240 V / 3.1 Nm3 AC 200–240 V / 3.1 Nm – 14 Nm3 AC 380–480 V / 3.1 Nm – 14 Nm
Motor Versions	Standard servomotorServomotor with hygienic design
Communication	PROFINET IRT, PROFIsafe, PROFIenergy, EtherNet/IP (from V6.3)
Safety Functions	STO, SBC, SS1-t (time controlled), SS1, SS2, SOS, SLS, SSM, SDI, SLA, SBT(* can be optionally activated using a license)
Motor Connection Technology	One-cable connection technology (OCC) with SPEED-CONNECT quick-release lock and rotatable, compact connector
Typical Control & Motion Control Compatibility	SIMATIC S7-1200 G2 / SIMATIC S7-1500 T-CPU / SIMOTION

Key Technical Specifications

Power Range: The Siemens SINAMICS S210 servo drive covers a wide power range from 50 W to 7 kW, fully catering to diverse mid-range industrial machinery and motion control demands.

Input Voltage: It supports dual voltage specifications, including 1-phase 200V–240V AC and 3-phase 380V–480V AC variants, adapting to different industrial power supply environments worldwide.

Network Connectivity: Equipped with native PROFINET RT/IRT interface to realize high-speed synchronous control with SIMATIC controllers. Select models additionally support EtherNet/IP, enabling seamless compatibility with third-party industrial control architectures.

Enclosure Rating: Features a standard IP20 protection rating, designed for secure and stable installation inside industrial control cabinets.

Safety Certifications: This high-reliability servo drive is certified up to SIL3 per EN 61508 and PL e per EN ISO 13849-1, ensuring superior functional safety for industrial automated production.

Typical Applications

Featuring fast acceleration, fast deceleration, and outstanding precision positioning capabilities, the Siemens SINAMICS S210 single-axis servo drive system is ideal for a wide range of OEM machinery and high-precision industrial automation applications. It delivers stable, high-dynamic motion performance for the following industrial equipment:

Packaging and labeling systems
Pick-and-place equipment and robotic handling systems
Digital printing presses
High-precision woodworking and ceramics processing machines

Watch our real stock video>>

Remarks

Product quality: 100% original brand new genuine products, supplied via official channels.
Warranty policy: 1 year official warranty is provided.
Lead time: Standard lead time is in stock; the exact delivery time is subject to the factory production schedule at that time.
Prices of industrial control products are subject to market and raw material fluctuations. Please contact online customer service for the latest quotes and delivery times.
