INVT GD10 Series Original Mini Variable Frequency Drive

As an authorized INVT electrical distributor, we provide 100% genuine INVT GD10 Series mini VFDs. This compact Goodrive10 series inverters are designed for small-power motor speed control, with stable V/f control, space-saving design and reliable protection. Widely used for small fans, pumps, conveyors and OEM equipment. Large in stock, global wholesale supported, fast delivery, full quality inspection before shipment.

${{shopModel.rebate>0?shopModel.discountPriceStr:shopModel.formattedAmount}} ~~$ {{shopModel.formattedAmount}}~~

COUPON

Quantity：

Estimated Delivery Date: Jun 05 - Jun 05

Frequently Asked Questions

How to inquire about other products I am interested in?

Are the products genuine official originals?

Can the delivery time be shortened?

Specifications

Description

Reviews

Product Overview & Technical Features

The INVT GD10 Series (Goodrive10 Series) is a flagship mini economical variable frequency drive developed by INVT Electric, specially designed for small-power industrial motor control and OEM supporting scenarios. It replaces traditional direct starting and speed regulation schemes, effectively reducing equipment impact, inrush current and operation noise, extending the service life of motors and terminal equipment.

With built-in full basic protection functions, user-friendly operation panel and standard Modbus-RTU RS485 communication interface, it fully meets the global industrial automation and light industry equipment standards. All products we supply are 100% original INVT genuine products, with complete certification and traceable serial numbers.

Parameter	Specification
Product Series	GD10 (Goodrive10) Series
Brand	INVT
Rated Power Range	0.2kW ~ 2.2kW (full series for small power loads)
Input Voltage Options	Single-phase 220V AC; Three-phase 220V AC; Three-phase 380V AC
Control Mode	Vectorized V/f Control + SVPWM Modulation
Output Frequency Range	0 ~ 400Hz
Speed Regulation Range	1:50
Speed Control Accuracy	±0.5%
Overload Capacity	150% rated current for 1 minute, 180% rated current for 10 seconds
Protection Level	IP20
Standard Configuration	Built-in braking unit, Modbus-RTU RS485 interface, removable operation panel
Adapted Motor	Three-phase AC asynchronous motor
Origin	Original INVT Factory
Certification	CE, RoHS, ISO, International Industrial Certification

Core Advantages of INVT GD10 Series

1.100% Original Genuine Guarantee

Authorized INVT distributor supply, zero counterfeit risk, full quality assurance, unique serial number for full traceability, complete certification documents available.

2.Ultra-compact & Maintenance-free Design

Miniature body for extreme space saving, 0.2kW~0.75kW models adopt fanless natural heat dissipation, suitable for dusty and flocculent harsh environments, no regular maintenance required.

3.Stable & Reliable Operation

High-precision vectorized V/f control, wide voltage input adaptation, built-in overcurrent, overvoltage, undervoltage, phase loss, overload full protection functions, long-term stable operation in complex working conditions.

4.Cost-effective OEM Special Solution

Full coverage of 0.2kW~2.2kW small power segment, rich basic functions including PID control, 16-step speed, DC braking, standard communication interface, perfect for batch OEM supporting.

5.Large Stock & Global Fast Delivery

2000+ units of full power models in local warehouse, support sample order and bulk wholesale, ship within 24-48 hours after payment, global door-to-door delivery available.
